Landslide Prevention Mesh

Landslide Prevention Mesh / Rockfall Drapes / Slope Protection Mesh / Cable Net Drapery / Rockfall Protection Wire Mesh

The Landslide Prevention Mesh inlcuding Active Protective Netting System and Passive Protective Netting System.

The Landslide Prevention Mesh were consists of high tensile rockfall netting, such as high tensile strength steel wire mesh, high tensile sprial rope , wire rope or ring net. With using any item of the high tensile rockfall protection mesh, mainly providing Active protective (Rock covering ) and Passive Protective (rockfall blocking). After a lot of testing in the projects, the Landslide Prevention Mesh now is widely used in Slopes Stabilization, Landslide Prevention, Avalanche Prevention, Debris Flow Barriers, Rockfall Protection etc.

When it’s using as Active Protection Mesh System, the Landslide Prevention Mesh are fastened to the slope tightly by the anchors and spike plates through prestressed tension. Then the boundary rope, sewing rope and connection clips will reinforce the Rock Fall Netting for solid and firm. When the landslide, rockfall and debris flow comes, the large stones or debris will be blocked by the rock fall netting and reduce the attack to the ground.

When it’s using as Passive Protection Mesh System, the steel post should be installed well with the foundation firstly, the Landslide Prevention Mesh will be fastened to the steel post and ground by support ropes & Anchors, it works together with buffering ring, and creating complete protection to the area.

The Popular Models of Active Landslide Prevention Mesh:

Tecco G65/3 Tecco G65/4 Tecco G80/4 Spider S3-130 Spider S4-130 GPS1 GPS2

The Popular Models of Passive Landslide Prevention Mesh :

RX-025 RX-050 RX-075 RXI-025 RXI-050 RXI-075 RXI-100 RXI-200 Ringnet 3/12/350

Our standard Landslide Prevention Mesh has been exporting to many customers from Europe, Russia, America, South Asia, Africa, Mideast etc. Any third-party inspection is acceptable before you placing an order, please contact with us for more detail information.
